Wood Kiln Dryer
We supply loading 40m³, 50m³, 60m³, 80m³, 100m³, 120m³, 150m³, 200m³.
Key words:
Category:
WhatsApp:
Wood Kiln Dryer
Specification and model of wood drying kiln
| Loading(m³) | Kiln Size-W*D*H(m) | Wood Pile Size-W*D*H(m) | Dry Heat Source | Fan Quantity | Consumption(KG/H) | Uint Power |
| 40 | 4.5*6.4*5.6 | 4.0*4.8*4.3 |
Steam Hote Water Heat Transfer Oil |
2 | 200 | 6 |
| 50 | 4.5*8.0*5.6 | 4.0*6.0*4.3 | 3 | 200 | 9 | |
| 60 | 6.6*6.4*5.6 | 6.0*4.8*4.3 | 3 | 250 | 9 | |
| 80 | 8.6*6.4*5.6 | 8.0*4.8*4.3 | 4 | 300 | 12 | |
| 100 | 8.6*8.0*5.6 | 8.0*6.0*4.3 | 5 | 350 | 15 | |
| 120 | 10.6*8.0*5.6 | 10.0*6.0*4.3 | 6 | 500 | 18 | |
| 150 | 12.8*8.0*5.6 | 12.0*6.0*4.3 | 8 | 600 | 24 | |
| 200 | 12.8*9.2*6.1 | 12.0*7.0*4.8 | 10 | 750 |
30 |
